Slingco - Reel Lifter, 5,000 lbs, ZLD09186

Slingco ZLD09186 Reel Lifter — 5,000 lb Capacity

The Slingco ZLD09186 Reel Lifter is a high-capacity, compact solution for safely loading, transporting, and dispensing wire and cable on-site. Engineered for utility construction and industrial applications, this rugged unit transforms a multi-person reel handling job into a single-operator task — boosting crew efficiency and reducing injury risk during cable reel operations. Built to ASME B30.20.1 standards with a 5,000 lb capacity and accommodating arbor sizes from 3" to 6".

Key Features

• 5,000 lb capacity built to ASME B30.20.1 standards for safe, rated reel lifting and dispensing
• Counterweighted bottom arm enables easy reel insertion by a single operator
• Side flipping eye secures reels in a non-rolling position during transport and setup
• Smooth rotation mechanism allows controlled, consistent cable unrolling during dispensing
• Accommodates arbor sizes from 3" to 6" for versatile use across a range of reel sizes
• 14.5 lbs — lightweight and portable despite 5,000 lb rated capacity
• Repair kits available for long-term reliability and serviceability in the field

Specifications

• Part Number: ZLD09186
• Type: Reel lifter
• Capacity: 5,000 lbs
• Standard: ASME B30.20.1
• Arbor Range: 3" to 6"
• Length: 21.125"
• Weight: 14.5 lbs
• Application: Wire and cable reel loading, transport, and dispensing — utility construction and industrial
• Vendor: Slingco

Ideal Applications

• Wire and cable reel handling during utility line construction requiring single-operator reel loading and dispensing
• Industrial and warehouse cable reel operations requiring a compact, high-capacity rated reel lifter
• Any utility or construction application requiring an ASME B30.20.1-compliant reel lifter for arbors from 3" to 6"

Part Number: ZLD09186 | Vendor: Slingco | Capacity: 5,000 lbs | Arbor Range: 3"–6" | Length: 21.125" | Weight: 14.5 lbs | Standard: ASME B30.20.1
