Ripley Tools - 1.26" Insulation Chamfer Tool 34760

Ripley Tools 34760 Insulation Chamfer Tool — 1.26" Max OD, 15kV–35kV

The Ripley Tools 34760 insulation chamfer tool creates precise, consistent 45-degree bevels on XLP cable insulation for 15kV to 35kV applications. Designed for use with pre-molded splices, elbows, and terminations, this tool delivers the accurate bevel geometry required for reliable, code-compliant high-voltage cable installations — fast and safely.

Key Features

• 45-degree bevel, 0.125" long — precision geometry for XLP insulation chamfering
• Cable OD range: 0.65" to 1.260" with fast, easy adjustment
• Recessed blades protect against operator injury and blade damage during use
• Designed for 15kV to 35kV cable termination and splicing prep
• Compatible with pre-molded splices, elbows, and terminations
• Replacement blade available: Part No. CB163

Specifications

• Part Number: 34760
• Bevel Angle: 45 degrees
• Bevel Length: 0.125"
• Cable OD Range: 0.65" – 1.260"
• Insulation Type: XLP (cross-linked polyethylene)
• Voltage Range: 15kV – 35kV
• Tool Diameter: 3-1/2"
• Weight: 10 oz
• Replacement Blade: CB163

Ideal Applications

• XLP cable insulation chamfering for 15kV–35kV systems
• Pre-molded splice, elbow, and termination preparation
• Utility underground cable installation and maintenance
• Industrial electrical cable prep requiring precise bevel geometry

Part Number: 34760 | Vendor: Ripley Tools | Replacement Blade: CB163
